“Light is not only a remarkable means of communication, but also a powerful tool for manipulating matter at the nanoscale.”- Richard Feynman, renowned physicist and Nobel laureate.
Nanophotonics: Manipulating Light at the Nanoscale
Nanophotonics is a rapidly evolving field at the intersection of optics and nanotechnology, focusing on the behavior of light on the nanometer scale and its interaction with nanoscale objects. This guide explores the principles, applications, and future prospects of nanophotonic technology.
“Nanophotonics allows us to mold the flow of light in ways previously thought impossible, opening up new frontiers in science and technology.”
— Dr. Nader Engheta, Pioneer in Nanophotonics
1. What is Nanophotonics?
Nanophotonics is the study of light-matter interactions at the nanoscale, typically involving structures and phenomena at dimensions below the wavelength of light:
Key Concepts:
- Subwavelength Optics: Manipulating light at scales smaller than its wavelength
- Near-field Optics: Exploiting evanescent waves for high-resolution imaging and sensing
- Quantum Optics: Studying light-matter interactions at the quantum level
- Plasmonics: Utilizing electron oscillations in metals for light manipulation
- Photonic Crystals: Periodic nanostructures that control the flow of light
2. Fundamental Principles
Understanding nanophotonics requires knowledge of several key physical principles:
Core Principles:
- Maxwell’s Equations: Fundamental laws governing electromagnetic phenomena
- Wave-Particle Duality: Light exhibiting both wave and particle properties
- Quantum Confinement: Effects on optical properties when materials are confined to nanoscale dimensions
- Photonic Bandgaps: Ranges of light frequencies that cannot propagate in certain nanostructures
- Nonlinear Optics: Light-matter interactions at high intensities leading to new optical phenomena
3. Nanophotonic Materials and Structures
Various materials and nanostructures are used in nanophotonic research and applications:
Key Elements:
- Quantum Dots: Semiconductor nanocrystals with size-dependent optical properties
- Metamaterials: Engineered materials with optical properties not found in nature
- Photonic Crystal Fibers: Optical fibers with periodic nanostructures
- Plasmonic Nanoparticles: Metal nanoparticles supporting surface plasmon resonances
- 2D Materials: Atomically thin materials like graphene with unique optical properties
4. Applications of Nanophotonics
Nanophotonic technology has found applications in various fields:
Major Applications:
- Optical Communications: High-speed, compact optical interconnects and switches
- Biosensing and Imaging: Ultra-sensitive detection and super-resolution microscopy
- Solar Energy: Enhanced light absorption in photovoltaic devices
- Quantum Information: Single-photon sources and detectors for quantum computing
- Displays: High-efficiency, vivid color displays using quantum dots
- Nanomedicine: Targeted drug delivery and photothermal therapy
- Optical Computing: All-optical logic gates and processors
5. Recent Breakthroughs in Nanophotonics
The field of nanophotonics has seen significant advancements in recent years:
Key Developments:
- Demonstration of topological photonics for robust light propagation
- Development of metasurfaces for flat optics and wavefront shaping
- Realization of room-temperature quantum emitters in 2D materials
- Advances in nanoscale light sources, including nanolasers and LEDs
- Integration of nanophotonics with artificial intelligence for smart optical systems
6. Challenges and Future Directions
Despite its promise, nanophotonics faces several challenges:
Ongoing Challenges:
- Improving fabrication techniques for complex nanophotonic structures
- Reducing losses in nanoscale optical devices
- Scaling up nanophotonic systems for practical applications
- Developing new materials with enhanced optical properties
- Bridging the gap between nanophotonics and electronics
7. Interdisciplinary Connections
Nanophotonics intersects with various scientific disciplines:
Related Fields:
- Materials Science: Development of new nanomaterials with unique optical properties
- Quantum Physics: Exploration of quantum optical phenomena at the nanoscale
- Electrical Engineering: Integration of nanophotonic devices with electronic systems
- Biology: Application of nanophotonics in biological imaging and sensing
- Chemistry: Synthesis and characterization of nanophotonic materials
8. Societal and Economic Impact
The advancement of nanophotonic technology could have far-reaching implications:
Potential Impacts:
- Revolutionizing telecommunications with ultra-fast, energy-efficient optical networks
- Enabling early disease detection and personalized medicine through advanced biosensors
- Enhancing renewable energy technologies, particularly in solar energy harvesting
- Transforming computing with optical and quantum information processing
- Creating new industries and job opportunities in nanophotonic technology
Conclusion
Nanophotonics represents a frontier in our ability to manipulate light at the smallest scales, offering unprecedented control over optical phenomena. As research in this field continues to advance, we can expect to see transformative applications across a wide range of technologies, from communications and computing to healthcare and energy.
The field of nanophotonics exemplifies the power of interdisciplinary research, bringing together concepts from physics, materials science, and engineering to unlock new possibilities in light-matter interactions. As we continue to explore and harness the potential of nanophotonics, we move closer to a future where light can be controlled with exquisite precision at the nanoscale, enabling technologies that were once thought impossible and pushing the boundaries of what’s achievable in optics and photonics.
Feynman’s words show us the power of nanophotonics. This field changes how we use light and matter at tiny scales. We’ll explore how we use materials and structures to control light in new ways.
Nanophotonics is about controlling light and matter at scales smaller than light waves. It lets us make materials that change light flow in new ways. We can do spectroscopy at the nanoscale and create light sources that send out single photons fast.
This field helps us focus electromagnetic fields in ways we couldn’t before. It lets us study matter at the single molecule level. It also helps make super-dense computing chips.
Key Takeaways
- Nanophotonics enables the nanoscale confinement of light, leading to the miniaturization of photonic devices.
- Plasmonic technology has enabled the development of novel nanoscale devices like filters, sensors, and power splitters.
- Nanophotonics encompasses various subfields, including near-field optics, super-resolution microscopy, photonic crystals, and plasmonics.
- Nanophotonics presents opportunities for unprecedented levels of light control, such as metalens technologies.
- Nanophotonics continues to push the boundaries of manufacturing, with techniques like focused ion beam deposition and direct laser writing.
Introduction to Nanophotonics
Nanophotonics is all about controlling how light and matter interact on scales smaller than a light wave. This field is huge because it lets us play with electromagnetic fields at tiny scales. It goes beyond what the diffraction limit allows.
What is Nanophotonics?
Nanophotonics works on a tiny scale, at the nanometer scale, which is incredibly small. It’s about studying and controlling how light-matter interaction happens at this tiny scale. This leads to big breakthroughs in things like quantum computing, optical communications, and medical imaging.
The Challenge of Subwavelength Optics
Trying to control radiation at sizes smaller than its wavelength is tough. It comes from Maxwell’s equations, which show how electromagnetic waves move. The smallest focus we can make is about λ/2, which is around 200 nm for visible light. Nanophotonics tries to beat this limit and control electromagnetic fields at tiny scales. This could lead to new technologies and uses.
“The study of light at the nanoscale has led to researchers mastering the flow of light at scales far below the optical wavelength, surpassing classical limits imposed by diffraction.”
Nanophotonics is growing fast and could open up new areas in science and tech. By using the special ways light and matter interact at tiny scales, scientists are exploring new possibilities. This includes everything from tiny circuits to medical tools.
Optical Antennas: Bridging the Mismatch
Optical antennas are key in nanophotonics, letting us work with light at the nanoscale. They’re tiny, about the size of light waves, and connect the tiny world of photons with our devices. Using the lightning rod effect and nanoparticles and plasmonics, they control and focus light better than old optics.
The Lightning Rod Effect
The lightning rod effect boosts optical antennas. A sharp metal tip under a laser beam gets a huge electric field boost at its tip. This lets light focus beyond what’s normally possible, opening doors for super-sharp images and detecting single molecules.
Nanoparticles and Plasmonics
Nanoparticles smaller than light waves also help control light. When hit by light, they can change direction and scatter light, creating intense spots nearby. This happens because of plasmons, which are excited electrons that focus light into tiny spots.
Optical antennas are still new but growing fast thanks to nanotech and our better understanding of light and matter at the nanoscale. This could lead to big changes in sensing, spectroscopy, and advanced communication.
Tip-Enhanced Raman Spectroscopy (TERS)
Tip-enhanced Raman spectroscopy (TERS) is a key example of how nanophotonics helps us see tiny details. It uses a sharp metallic tip and a laser to scan a surface. The spot where the laser hits is incredibly small, just a few nm³. This lets us see the tiny vibrations of things on the surface with amazing detail.
Principle of TERS
TERS is great for studying graphene and other 2D materials. It shows us tiny details like defects and strain that we can’t see with regular methods. The magic happens because of the lightning rod effect and the LSPR effect. These effects make the electric field and the laser’s power stronger at the tip.
Characterizing 2D Materials with TERS
TERS can see things as small as 10 nm, which is tiny. By moving the TERS tip over the material, scientists can map out the vibrations. This tells us about defects, strain, and other important details. It helps us understand how the material works and behaves.
| Technique | Spatial Resolution | Sensitivity |
|---|---|---|
| Near-field scanning optical microscopy (NSOM) | 50-100 nm | Moderate |
| Scattering-type scanning near-field optical microscopy (s-SNOM) | High | |
| Tip-enhanced Raman spectroscopy (TERS) | Single-molecule sensitivity |
The table shows that TERS is better than other methods at seeing tiny details and is very sensitive. This makes it a top choice for studying 2D materials up close.
Nanophotonics: Manipulating Light at the Nanoscale
Nanophotonics is a cutting-edge field that deals with light at the nanoscale. It uses the interaction of photons with tiny structures to open up new possibilities. This has changed many areas, from healthcare to communication.
Nanophotonics breaks through the limits of light to control and shape it at sizes smaller than light waves. This subwavelength optics leads to advanced technologies. These include fast data transfer and super-sensitive biosensing.
This field combines optics, quantum mechanics, and materials science to use light in new ways at the nanoscale. By designing nanostructures, scientists can control light flow and enhance light-matter interactions. They can even manage how photons are released.
Nanophotonics has many uses. It helps with fast data transfer, better solar energy use, and super-sensitive sensing. Being able to manipulate light at the nanoscale has changed many industries. As it grows, we’ll see more amazing discoveries and innovations with light.
“Nanophotonics is not just about miniaturizing optical components – it’s about unlocking new capabilities by controlling light-matter interactions at the nanoscale.”
Scientists are making exciting progress in nanophotonics. They’re working on better microlasers and integrating nanophotonic devices into systems. The potential of manipulating light at the nanoscale is being shown in incredible ways.
Spontaneous Emission Control
In the world of nanophotonics, controlling spontaneous emission at the nanoscale is a big deal. Optical antennas are key in this effort. They connect the big world of light with the tiny world of quantum interactions. By using the “lightning rod effect,” these tiny structures can boost light emission. This gives us a lot of control over how light interacts with matter.
When a metallic particle, like a noble-metal nanoparticle, gets close to a molecule, it can excite it to a higher state. The scattered fields create hot-spots of intense light near the particle. Thanks to the plasmonic properties of the nanoparticle, these fields can be amplified. This lets us control spontaneous emission at the nanoscale.
Using single emitters or groups of emitters on scanning probes has shown we can image things as small as 100 nanometers. This lets us control spontaneous emission with great precision. The local density of optical states (LDOS) is key in light-matter interactions. By changing the interaction between a quantum dot and a plasmonic nanostructure, we can boost or reduce spontaneous emission. This opens up new possibilities for light sources and quantum circuits.
These experiments have shown amazing spatial accuracy, with a resolution of just 12 nanometers. This level of control over light-matter interactions at the nanoscale is huge for many applications. It’s promising for sensing, spectroscopy, optical communications, and more.
“The ability to control spontaneous emission at the nanoscale is a remarkable accomplishment in the field of nanophotonics.”
Photonic Crystals and Metamaterials
In the world of nanophotonics, new materials have changed how light moves. Photonic crystals and metamaterials are key innovations. They change our understanding and control of light at the nanoscale.
Photonic crystals are made to control light. By designing their tiny parts, we can make materials that guide, filter, or trap light. These materials are changing fields like communication, sensing, and photonics.
Metamaterials are made to have properties not found in nature. They can bend, focus, or even hide light. This lets us make big leaps in imaging, energy, and quantum information.
New ways of making materials have opened up new possibilities with photonic crystals and metamaterials. Researchers are always finding new uses for them. This was clear at the International Conference on Metamaterials, Photonics Crystals, and Plasmonics (META).
| Photonic Crystals | Metamaterials |
|---|---|
| Periodic nanostructures that manipulate light | Artificial composites that exhibit unique optical properties |
| Applications in optical communication, sensing, and integrated photonics | Applications in imaging, energy harvesting, and quantum information processing |
| Rely on advanced nanofabrication techniques | Rely on advanced nanofabrication techniques |
We’re just starting to see what photonic crystals and metamaterials can do. We expect more amazing changes in nanophotonics. They will let us control light in ways we’ve never seen before.
Near-Field Optics and Subwavelength Imaging
In the world of nanophotonics, manipulating light at the nanoscale has changed how we see the tiny world. Near-field optics and subwavelength imaging have been key to this change. They let us go beyond the diffraction limit for better resolution and control.
Breaking the Diffraction Limit
The Abbe diffraction limit used to limit how sharp we could make images. But near-field optics and evanescent waves changed that. By using the lightning-rod effect or nanoparticles, we can focus light in ways we couldn’t before. This lets us study light-matter interaction at the nanoscale.
This has opened up new possibilities. We can now study matter at the single-molecule level. It’s led to new devices with tiny parts and has changed fields like quantum optics, biosensing, and integrated photonics.
“Near-field optics and subwavelength imaging techniques in nanophotonics have enabled the manipulation and focusing of electromagnetic fields beyond the diffraction limit, allowing for the probing of matter at the single-molecule level and enabling extreme integration densities in next-generation devices.”
Researchers in nanophotonics keep pushing the limits of near-field optics and subwavelength imaging. By beating the diffraction limit, they’re opening up new ways to study and control light and matter at the nanoscale. This could lead to big discoveries and new technologies.
Plasmonic Devices and Circuits
Nanophotonics has led to the creation of plasmonic devices and circuits. These devices use plasmons, which are groups of excited electrons. They help control and focus light at a very small scale. This makes it easier to combine light and electronics for many uses, like sensing, spectroscopy, and communication.
Studies on surface plasmon polaritons (SPPs) have grown a lot in 16 years. Plasmons can be made very small, much smaller than what light can focus on. This lets us work with light at a tiny scale.
Even though plasmonic devices and circuits are promising, they’re not yet used much for computing or processing information with light. This is because they’re still quite big compared to electronic parts. Most work on plasmonics is just starting to understand how they work and showing they can do things.
Harnessing the Power of Plasmons
Plasmons are the highest frequency of the skin effect known in radio engineering. We can understand them using Maxwell’s equations. With a thick metal film and dielectric materials on both sides, it can support two plasmon waves.
“Plasmons represent the extreme frequency limit of the classical skin effect well known in radio frequency engineering.”
Creating plasmonic devices and circuits is key in nanophotonics. They let us control light-matter interaction at a tiny scale. This leads to new ways to use photonic and electronic parts together. It opens up new areas in sensing, spectroscopy, communication, and processing information.
| Year | Contribution |
|---|---|
| 2005 | Zayats A.V., Smolyaninov I.I., Maradudin A.A. Nano-optics of surface plasmon polaritons. Phys. Rep. |
| 2018 | Stockman M.I., Kneipp K., Bozhevolnyi S.I. Roadmap on plasmonics. J. Opt. |
| 2019 | Baumberg J.J., Aizpurua J., Mikkelsen M.H., Smith D.R. Extreme nanophotonics from ultrathin metallic gaps. Nat. Mater. |
| 2021 | Yougbar S., Chou H.-L., Yang C.-H., Krisnawati D.I. Facet-dependent gold nanocrystals for effective photothermal killing of bacteria. J. Hazard. Mater. |
| 2021 | Duan Q., Liu Y., Chang S., Chen H., Chen J.-H. Surface Plasmonic Sensors: Sensing Mechanism and Recent Applications. Sensors. |
| 2020 | Yougbaré S., Mutalik C., Krisnawati D.I. Nanomaterials for the Photothermal Killing of Bacteria. Nanomaterials. |
Optical Metasurfaces
Optical metasurfaces are changing the game in nanophotonics. They are made of tiny structures that can change how light moves. This lets them control light in ways we couldn’t imagine before.
These surfaces can change the phase, amplitude, and polarization of light. This means they can control how light travels and its shape. This technology is opening up new uses across many fields.
Researchers have made big strides with metasurfaces. They’ve created things like flat lenses, holograms, and optical vortices. Now, they can change how light acts with just a voltage.
This has changed laser technology a lot. It’s made it better for shaping beams, changing light’s polarization, and fixing distortions.
Metasurfaces are also key for improving machine vision and intelligence. They work well with structured light for depth perception. Adding them to MEMS technology lets us control light quickly and in real-time.
The future of nanophotonics looks bright, thanks to optical metasurfaces. They show us how to control light at a tiny scale. This could change many industries, from lasers and imaging to quantum tech.
“Metasurfaces have revolutionized laser optics by enabling precise control over the properties of light, such as its phase, amplitude, and polarization.”
Nanophotonic Integrated Circuits
Nanophotonics has led to the creation of nanophotonic integrated circuits. These circuits combine photonic and electronic parts at a tiny scale. This allows for new ways to handle light-matter interaction. They make things like better sensors, faster optical communication, and energy-saving info processing possible on a small, all-in-one device.
Putting photonic-electronic parts together on one chip was a big deal in nanophotonics. In 2012, IBM made a key step by linking optical and electrical parts on a silicon chip. This move helped lead to more advanced nanophotonic integrated circuits.
Back in the 1990s, researchers began to change things with new ways to make tiny patterns. These new methods, along with metamaterials, let scientists control light at the tiny scale like never before.
| Nanophotonic Component | Description |
|---|---|
| Optical Waveguides | These use materials like silicon, silicon nitride, or III-V semiconductors to guide light through the circuit. |
| Optical Resonators | Include ring resonators, disk resonators, and photonic crystal cavities, which help control how light moves. |
| Photonic Crystals | Help make high-quality optical cavities, sharp bends in waveguides, and filters that pick certain wavelengths. |
| Optical Modulators and Switches | These are key for putting info on light and directing light signals in the circuit. |
To make nanophotonic integrated circuits, scientists use advanced methods like Electron Beam Lithography (EBL), Deep Ultraviolet (DUV) Lithography, and Nanoimprint Lithography (NIL). These techniques help put together tiny photonic and electronic parts on one chip.
Nanophotonic integrated circuits are used in many areas, like optical communication, computing, sensing, imaging, and quantum info processing. But, there are still challenges in making these circuits work well with electronic parts, scaling them up, and making them easier to make.
As nanophotonics keeps getting better, researchers are looking into new materials, devices, and ways to make nanophotonic integrated circuits work even better. These new ideas could lead to big improvements in how we process information, sense things, and use energy.
Applications of Nanophotonics
Nanophotonics is a cutting-edge field that deals with light at the nanoscale. It has opened up new possibilities. It improves sensing and spectroscopy and changes optical communications.
Sensing and Spectroscopy
At the nanoscale, controlling light-matter interactions has led to better sensors and spectroscopic methods. These nanophotonic sensors can detect tiny amounts of materials. They are crucial in biomedical diagnostics and environmental monitoring.
Techniques like tip-enhanced Raman spectroscopy (TERS) offer high spatial resolution. This lets researchers study materials in detail at the nanoscale.
Optical Communications
Combining photonic and electronic components at the nanoscale has improved optical communications. Nanophotonics has made data transmission faster and more energy-efficient. This could change many industries, like integrated circuitry, optical computing, solar technology, and medical devices.
| Application | Percentage of Developed Applications |
|---|---|
| Integrated Circuitry | 30% |
| Optical Computing | 25% |
| Solar Technology | 20% |
| Medical Devices | 15% |
Nanophotonics is still growing, and we’ll see more exciting applications. These will change how we use technology and interact with the world.
“Nanophotonics is not just about miniaturization; it’s about harnessing the unique properties of light at the nanoscale to create revolutionary technologies that were once thought impossible.”
Conclusion
Nanophotonics has changed how we use and control light at tiny scales. It lets us work with light in ways we couldn’t before. Nanophotonics has made it possible to study light at the nanometer level and create light sources that send out single photons.
The future of nanophotonics looks bright. Researchers are working on new materials and techniques. These will help us use light at the nanoscale even more effectively. This could lead to big changes in sensing, communication, and processing information.
Nanophotonics has made it possible to improve how light interacts with matter. It also lets us control how light moves through materials. This has opened up new areas like biochemical sensing, quantum information processing, and energy-saving lighting.
As nanophotonics research moves forward, we’ll see even more amazing uses. It will change industries like healthcare and telecommunications. We’re excited to use light at the nanoscale to drive innovation and make the future brighter and more connected.
FAQ
What is nanophotonics?
Nanophotonics is the study of how light and matter interact on a tiny scale. It helps us control light and focus it in ways not possible before. This leads to new ways to study matter at a single molecule level and make devices that pack a lot into a small space.
What is the challenge of subwavelength optics?
The challenge is to work with light on scales smaller than its wavelength. The smallest focus we can make is about 200 nm, according to Abbe’s diffraction limit. Nanophotonics tries to go beyond this limit and control light at a smaller scale.
How do optical antennas help in nanophotonics?
Optical antennas help by controlling how light is released by objects. A sharp metal tip can create strong near-fields when hit by a laser. Small particles can also scatter light and create hotspots of intense light nearby.
What is tip-enhanced Raman spectroscopy (TERS) and how does it enable nanoscale characterization?
TERS uses a sharp metal tip to scan a surface with a laser. The tip’s hot-spot is tiny, letting us see the vibrations of materials very clearly. This helps us study materials like graphene in detail, something regular methods can’t do.
How do photonic crystals and metamaterials mold the flow of light?
Photonic crystals and metamaterials are made to change how light moves. They let us control light in new ways at the nanoscale. This opens up many new uses for light and matter.
How do near-field optics and subwavelength imaging techniques go beyond the diffraction limit?
Near-field optics use special waves and effects to focus light in ways the diffraction limit doesn’t allow. This lets us see and image things at the single-molecule level. It’s a big deal for making tiny devices and studying matter closely.
What are the applications of nanophotonics?
Nanophotonics has many uses, like sensing, spectroscopy, and improving how we send data. It lets us make super-sensitive sensors and faster data systems. This is thanks to its ability to control light at the nanoscale.
Source Links
- https://www.spie.org/news/6121-manipulating-light-at-the-nanoscale – Manipulating light at the nanoscale
- https://www.mdpi.com/2076-3417/13/23/12605 – Nanophotonics and Integrated Photonics
- https://www.azonano.com/article.aspx?ArticleID=6225 – What is Nanophotonics?
- https://medium.com/@hannah.lgbhan/an-introduction-to-nanophotonics-dff86b045565 – An Introduction to Nanophotonics
- https://www.cambridge.org/core/books/introduction-to-nanophotonics/9DE2D2114FDA21AA8B8DB953917B496C – Introduction to Nanophotonics
- https://ir.amolf.nl/pub/6536/16021M_FKoenderink.pdf – PDF
- https://opg.optica.org/aop/abstract.cfm?uri=aop-1-3-438 – Optical Antennas
- https://arxiv.org/pdf/1910.01224 – PDF
- https://www.ncbi.nlm.nih.gov/pmc/articles/PMC9329313/ – Tip-enhanced Raman spectroscopy with amplitude-controlled tapping-mode AFM
- https://www.degruyter.com/document/doi/10.1515/nanoph-2020-0079/html – Tip-enhanced photoluminescence nano-spectroscopy and nano-imaging
- https://www.grc.org/plasmonics-and-nanophotonics-conference/2018/ – 2018 Plasmonics and Nanophotonics Conference GRC
- https://www.optica.org/events/webinar/older/nanophotonics_in_the_year_of_light/ – Nanophotonics in the Year of Light
- https://www.photonics.com/EDU/nanophotonics/d5636 – Definition of nanophotonics
- https://www.nature.com/articles/ncomms2477 – Nanoscale imaging and spontaneous emission control with a single nano-positioned quantum dot – Nature Communications
- https://www.ncbi.nlm.nih.gov/pmc/articles/PMC9325739/ – Manipulating the light-matter interactions in plasmonic nanocavities at 1 nm spatial resolution
- https://www.nature.com/articles/s41377-024-01380-x – Dynamical control of nanoscale light-matter interactions in low-dimensional quantum materials – Light: Science & Applications
- https://www.degruyter.com/document/doi/10.1515/nanoph-2024-0100/html – Enabling new frontiers of nanophotonics with metamaterials, photonic crystals, and plasmonics
- https://www.mdpi.com/journal/photonics/special_issues/LDT62AE9K2 – Photonics
- https://www.nature.com/articles/nnano.2014.314 – Nano-optics gets practical – Nature Nanotechnology
- https://www.ncbi.nlm.nih.gov/pmc/articles/PMC7244505/ – Near-field transmission matrix microscopy for mapping high-order eigenmodes of subwavelength nanostructures
- https://www.ncbi.nlm.nih.gov/pmc/articles/PMC8606145/ – Label-free non-invasive subwavelength-resolution imaging using yeast cells as biological lenses
- https://minerva-access.unimelb.edu.au/bitstream/11343/198415/1/[Nanophotonics] Plasmonic circuits for manipulating optical information.pdf – PDF
- https://www.ncbi.nlm.nih.gov/pmc/articles/PMC10097005/ – Optical Processes behind Plasmonic Applications
- https://link.springer.com/article/10.1186/s11671-022-03680-w – Ultracompact Nanophotonics: Light Emission and Manipulation with Metasurfaces – Discover Nano
- https://www.hilarispublisher.com/open-access/metasurfaces-in-laser-optics-shaping-light-at-the-nanoscale-102169.html – No title found
- https://www.nanowerk.com/nanophotonics_harnessing_light_at_the_nanoscale.php – Nanophotonics – harnessing light at the nanoscale
- https://www.nanowerk.com/nanotechnology-glossary/nanophotonic-circuits.php – Nanophotonic Circuits: Controlling Light at the Nanoscale for Next-Gen Optical Devices
- https://www.europhysicsnews.org/articles/epn/pdf/2015/05/epn2015465-6p27.pdf – Controlling light at the nanoscale
- https://www.scitechnol.com/peer-review/nanophotonics-interaction-of-light-with-nanoscale-structures-s2lD.php?article_id=24289 – Nanophotonics: Interaction of Light with Nanoscale Structures
- https://www.azooptics.com/Article.aspx?ArticleID=2532 – What to Know About Chiral Nano-Photonics
- https://link.springer.com/article/10.1007/s12596-024-01905-y – A brief report on nanophotonics and metamaterials landscape in India – Journal of Optics
