Tellurene is a new, two-dimensional semiconductor that’s making waves in the world of advanced materials. It’s part of a group of 15 elemental 2D materials, and it’s seen as a big deal¹. First talked about in 2017, it’s now getting lots of attention for its special properties in electronics and light².

What You Must Know About Tellurene

Aspect	Key Information
Definition	2D allotrope of tellurium with buckled hexagonal structure, exhibiting unique anisotropic electrical properties and high environmental stability compared to other monoelemental 2D materials.
Materials	High-purity tellurium crystals (5N+) Substrates: SiO₂/Si, mica, PET Intercalation agents: Li, Mg Passivation layers: h-BN
Properties	Bandgap: 0.92-1.18 eV (tunable) High carrier mobility (2,500 cm²/V·s) Anisotropic conductivity ratio: 10:1 Piezoelectric coefficient: 110 pm/V
Applications	Electronics: High-speed FETs, valleytronic devices Optoelectronics: Broadband photodetectors (UV-THz) Sensing: Strain/pressure sensors with 0.1% resolution
Fabrication Techniques	Mechanical exfoliation (Scotch tape method) Liquid-phase exfoliation (NMP solvent) Chemical vapor deposition (450-550°C) Molecular beam epitaxy (UHV conditions)
Challenges	Ambient oxidation (TeO₂ formation) Layer number-dependent properties High production costs (ultra-high vacuum) Limited large-area synthesis methods

Tellurene is really interesting because of its structure. It has a special crystal shape that lets it do many things at once. This makes it useful for electronics, sensors, and energy devices².

The properties of tellurene are quite fascinating. The most stable form, called the γ-phase, is very special. It has a unique energy gain of about 53 meV per atom¹. It also has amazing electronic properties, with a bandgap that changes depending on how thick it is¹.

Key Takeaways

Tellurene is a cutting-edge 2D material with multifunctional properties
First predicted in 2017, it represents a significant breakthrough in materials science
Exhibits unique electronic, thermal, and optical characteristics
Potential applications in electronics, sensors, and energy technologies
Demonstrates exceptional structural and electronic versatility

What is Tellurene?

Tellurene is a two-dimensional material that has caught the eye of scientists. It’s different from regular tellurium because of its unique structure and electronic properties³. This makes it very promising for use in electronics and semiconductors.

Understanding the Basis of Tellurene

The structure of tellurene is quite fascinating. It was first made in 2017, which was a big step forward in material science⁴. Its special helical shape makes it stand out from other 2D materials³.

Composition and Crystal Structure

The way tellurene is put together is complex and interesting. It has a unique structure because of its trigonal crystal lattice⁵. Scientists have found several important features:

Hexagonal nanoplates that are 6 to 10 μm wide³
It can be very thin, from one layer to tens of nanometers⁵
It has helical chains with a three-fold symmetry⁵

Property	Characteristic
Bandgap	0.35 eV (trigonal form)⁵
Carrier Mobility	Up to 10³ cm²V⁻¹s⁻¹³
Optical Absorption	Exceeds 10⁵ cm⁻¹³
Ion/Ioff Ratio	Approximately 10⁵⁵

The structure of tellurene is a major breakthrough in material science. It opens up new possibilities for electronics and semiconductors.

The Discovery of Tellurene

The journey of tellurene research is a major breakthrough in two-dimensional materials science. Tellurene is a nanomaterial that has caught the eye of scientists globally. It has unique electronic and structural properties⁶.

The synthesis of tellurene is a big deal in material science. In 2017, scientists first made this material. This achievement has opened up new ways for technology to advance⁶.

Key Milestones in Tellurene Development

Initial theoretical predictions of material properties
First experimental synthesis in 2017
Characterization of electronic band structure
Exploration of potential applications

Breakthrough Research Characteristics

Tellurene research has shown it has amazing qualities. It stands out from other two-dimensional materials. The material has:

A band gap that can change from 1.0 eV to 0.3 eV based on thickness⁷
High electron mobility of about 700 cm²/V·s⁷
Dynamic stability confirmed through phonon dispersion studies⁷

Innovative Detection Capabilities

Tellurene is not just scientifically important. It also has great potential in advanced sensing technologies. It can detect small amounts of harmful gases like nitrogen dioxide and carbon monoxide. This shows it is very sensitive to the environment⁶.

The discovery of tellurene is a key moment in nanomaterial research. It offers new chances for technological innovation.

Researchers are still learning about tellurene. They are exploring its full potential. This is helping us understand two-dimensional materials better and their possible uses⁶.

Unique Properties of Tellurene

Tellurene is a groundbreaking two-dimensional material with amazing properties. It stands out in advanced materials science. As researchers explore it, tellurene’s unique traits show promise for new technologies⁸.

Tellurene is a complex and fascinating material. It has remarkable potential in many scientific fields. Its special features make it a top choice for advanced material research advanced material research.

Electrical Conductivity Insights

Tellurene has unique electrical properties. It’s different from other two-dimensional materials. Its electronic structure shows unique carrier mobility with some amazing traits:

Tunable bandgap ranging from 0.31 eV (bulk) to 1.17 eV (2-layer)
Metallic behavior under specific conditions
High hole mobility reaching theoretical values of approximately 1E5 cm2/Vs⁸

Thermal Stability

Tellurene’s thermal properties are impressive. It keeps its structure at different temperatures. This makes it great for high-temperature electronic and energy devices⁹.

Optical Characteristics

Tellurene’s optical properties are intriguing. It can change its electronic structure with layer thickness. This opens up new possibilities for optoelectronic technologies⁸.

Property	Characteristic	Value Range
Bandgap	Direct/Indirect	0.31 – 1.3 eV
Carrier Mobility	Hole Mobility	Up to 1E5 cm2/Vs
Layer Dependence	Electronic Structure	Highly Anisotropic

As researchers learn more, tellurene’s uses are growing. It’s seen as a game-changer in materials science and electronics⁹.

Applications of Tellurene

Tellurene is a groundbreaking material with huge potential in many fields. Its unique electronic properties make it great for electronics, renewable energy, and photonics¹⁰.

Electronics and Semiconductors

In electronics, tellurene shows amazing performance. It has field-effect mobilities of about 700 cm²·V⁻¹·s⁻¹ and ON/OFF ratios near 10⁶¹⁰. This makes it a strong candidate for future semiconductor devices¹¹.

Renewable Energy Technology

Tellurene’s properties are also beneficial for renewable energy. Its bandgap can be tuned from 0.35 eV to 1.2 eV, which is great for solar cells¹². Its high hole mobility of about 1,300 cm²·V⁻¹·s⁻¹ boosts its energy conversion capabilities¹².

Potential in Photonics

Tellurene’s optical features are exciting for photonics. It shows outstanding phototransistor performance, with:

Responsivity of 0.96 A/W at 1.55 μm wavelength¹²
Detectivity of 2.2 × 10⁹ Jones¹²
Photocurrent anisotropic ratio of 2.9¹²

These features suggest tellurene’s potential in infrared imaging and optical communications¹².

How Tellurene Compares to Other 2D Materials

The world of two-dimensional materials is growing, with tellurene being a new and exciting addition. To understand tellurene, we must compare it with other 2D materials. This comparison shows its unique features and possible uses¹³.

Exploring Structural and Electronic Characteristics

Tellurene has special properties that make it stand out. Its Young’s modulus is about 27 GPa, and it can stretch over 30% without breaking¹³. These traits make it great for new technologies.

Comparative Analysis with Graphene

Comparing tellurene to graphene shows some big differences:

Tellurene has unique electronic properties with variable band gaps
It has a lower formation energy than materials like MoS2 and silicene¹³
Its electronic properties change with strain, making it more flexible

Transition Metal Dichalcogenides Comparison

Tellurene’s electronic properties change with its thickness. The band gaps go from 0.82 eV for bilayer α-Te to 0.03 eV for few-layer β-Te¹³.

Unique Advantages of Tellurene

Tellurene has several breakthrough advantages:

It can handle a lot of strain, up to -24% in one direction¹³
It’s great for making high-performance electronic devices
It can change its electronic state in many ways

Researchers have found many stable phases of tellurene using advanced methods. This shows its wide range of possible uses¹⁴.

The Challenges of Working with Tellurene

Research on tellurene faces big hurdles in making reliable synthesis and manufacturing processes. Turning this promising material into something useful is a tough task. It involves solving complex scientific problems that scientists are still working on.

Synthesis and Fabrication Hurdles

Making tellurene is full of technical challenges. There are several key issues in creating high-quality samples:

Limited scalable production methods¹⁵
Complexity of maintaining material integrity during fabrication¹⁶
Variations in electronic properties with thickness changes¹⁵

Stability and Scalability Concerns

Creating consistent tellurene samples is a big challenge. The material’s charge carrier mobility drops a lot when it gets close to nanometer scales. This is a big problem for electronic uses¹⁵.

As the material gets thinner, charge interactions become more localized. This affects how well the material works¹⁶.

Economic Considerations

The cost of making tellurene is a big barrier to its use. Making it requires advanced methods like molecular beam epitaxy and physical vapor deposition. These methods need special equipment and precise control¹⁶.

This makes production expensive, making it hard to use tellurene on a large scale.

Despite these challenges, tellurene’s potential in new technologies keeps scientists working hard¹⁵. They are hopeful about solving these problems and unlocking tellurene’s full potential¹⁶.

Future Research Directions

The field of tellurene research is growing fast, offering new chances for science and tech. Our study of this 2D material shows promising areas for more research¹⁷.

Innovations in Material Science

Researchers are finding exciting uses for tellurene. It has special traits that make it great for new tech:

Bandgap tunability across different allotropes¹⁷
Exceptional optical anisotropy in UV-Vis regions¹⁷
Versatile electronic properties⁵

Potential Collaborations

Working together across fields is key to moving tellurene research forward. Possible partnerships could be in:

Materials science and electronic engineering
Quantum computing development
Semiconductor device innovation

Impact on Technology Development

Tellurene’s uses are growing fast. Recent findings show it has big tech potential:

Field-effect transistors with mobility up to 700 cm²/V·s⁵
Transistor devices staying stable in air for two months⁵
Nanoscale device fabrication using thin tellurium flakes⁵

As we learn more, tellurene research opens up new paths in electronic and quantum tech¹⁷⁵.

Environmental Considerations

Understanding tellurene’s environmental impact is key. It involves looking at its material properties and how sustainable it is. Scientists are studying the ecological footprint of new materials like tellurene¹⁸.

Sustainability Landscape

Tellurene has a complex environmental profile. Tellurium, the main element, is very rare in Earth’s crust. It’s found in tiny amounts, from one to five parts per billion¹⁸.

This rarity makes it hard to produce tellurene materials sustainably.

Global tellurium production averages 450-470 metric tons annually¹⁸
Primary production sources include deposits in China and Sweden¹⁸
Tellurium contamination near industrial sites remains a critical environmental concern¹⁸

Recycling and Lifecycle Analysis

Knowing tellurene’s material properties shows its potential for new technologies. Its lifecycle analysis suggests it can be recycled well. This is good news for the electronic and semiconductor industries¹⁹.

Environmental Parameter	Tellurene Characteristics
Thickness Range	0.85 nm to 53 nm¹⁹
Lateral Dimensions	10-50 μm¹⁹
Bandgap	0.35 eV at room temperature¹⁹

Research into tellurene’s environmental sustainability is ongoing. It aims to make production methods greener and improve recyclability¹⁸.

Conclusion: The Future of Tellurene

The world of tellurene research is growing fast, with new uses in many fields. Tellurene is a groundbreaking 2D material with huge potential in electronics and semiconductors scientific exploration²⁰.

Tellurene is making big waves in electronics, thanks to its special properties. For example, tellurium-based field-effect transistors have a hole mobility of up to 1370 cm² V⁻¹ s⁻¹ at room temperature. This is much better than what we had before²⁰. This could change how we design and make semiconductors.

As scientists keep studying tellurene, they find more ways it can change technology. Its great electrical and thermal properties make it key for future tech. More research is needed to use tellurene in the latest electronics and photonics²¹.

The story of tellurene shows how fast materials science can move. With more research and teamwork, tellurene could lead to big breakthroughs in tech. We can expect to see many exciting developments in the future.

FAQ

What exactly is tellurene?

Tellurene is a new 2D material made of tellurium atoms. It has a unique helical chain structure. This makes it different from bulk tellurium and other 2D materials.

How is tellurene different from other 2D materials like graphene?

Tellurene has a special helical chain structure. It is very conductive and has a tunable bandgap. This makes it great for advanced electronics and optoelectronics.

What are the primary potential applications of tellurene?

Tellurene is promising for many fields. It could be used in next-gen electronics, semiconductors, and renewable energy. It’s also good for thermoelectric devices and advanced photonics.

What challenges exist in tellurene production?

Making high-quality tellurene is hard. It’s hard to keep it stable and scale up production. Researchers are working on better ways to make it, like mechanical exfoliation and chemical vapor deposition.

What makes tellurene’s electrical properties unique?

Tellurene is very conductive with high carrier mobility. Its unique structure makes it great for electronics and semiconductors. It could improve current tech.

Is tellurene environmentally sustainable?

Scientists are looking into tellurene’s sustainability. They’re studying tellurium’s abundance and how to extract it. They also want to know about energy use and recyclability.

What future research directions are being explored for tellurene?

Researchers are working on new ways to make tellurene better. They’re looking at doping, making heterostructures, and studying strain. They also want to use it in next-gen electronics and quantum computing.

How stable is tellurene under different conditions?

Tellurene is very stable at high temperatures. But scientists are still studying it. They want to know how it performs in different conditions to make it even better.
